詳細說明
AKS2-200,AKS2-250,AKS2-300,AKS2-350,AKS2-420,AKS2-500,AKS2-600,AKS2-630,擺缸液壓馬達
AKS2擺缸液壓馬達技術參數
AKS2擺缸液壓馬達技術參數
| 型號 | 理論排量(ml/r) | 額定壓力Mpa | 尖峰壓力Mpa | 額定扭矩(n.m) | 單位扭矩(n.m/mpa) | 連續轉速(r/min) | 最高轉速(r/min) | 最大功率（KW） | 重量(KG) |
| AKS2-200 | 192 | 25 | 42.5 | 750 | 30 | 0.7-550 | 800 | 59 | 51 |
| AKS2-250 | 251 | 25 | 42.5 | 980 | 39.2 | 0.7-500 | 800 | ||
| AKS2-300 | 304 | 25 | 40 | 1188 | 17.5 | 0.7-500 | 750 | ||
| AKS2-350 | 347 | 25 | 37.5 | 1355 | 54.2 | 0.7-450 | 750 | ||
| AKS2-420 | 425 | 25 | 35 | 1658 | 66.3 | 0.7-450 | 750 | ||
| AKS2-500 | 493 | 25 | 35 | 1923 | 76.9 | 0.7-450 | 700 | ||
| AKS2-600 | 565 | 25 | 30 | 2208 | 88.3 | 0.7-400 | 700 | ||
| AKS2-630 | 623 | 25 | 28 | 2433 | 97.3 | 0.7-400 | 650 |
