詳細說明
GAB410-2-5,GAB410-2-6,GAB410-2-7,AB-GAB 二位二通多用途(管式/板式)電磁閥,生產廠家,價格
產品特點：
AB,GAB多用途電磁閥是引進日本CKD公司產品，適用于多種介質(空氣、煤氣、水各種油類）及真空控制，性能好，壽命長，應用范圍廣。
型號說明：G AB 3 10 — — — — ︳ ︳ ︳ ︳ ︳ ︳ ︳ ︳ 板接式：G 二位二通 系列編號 10為常閉型 管接螺紋編號 通徑編號 閥體.密封件 電壓規格 管接式：不標 3為小規格 材料組合代號 4為大規格
圖形符號：
技術參數：
| 項目/型號 | 接管 | 公稱通徑 | CV值 | 有效截面積 | 最高工作壓差(MPa) | ||||||
| 螺紋 | mm | mm2 | 空氣 | 水、煤油 | 油(50cst) | 蒸氣 | |||||
| AC | DC | AC | DC | AC | DC | DC | |||||
| AB310-1-1 | ZG1/8 | 1.5 | 0.1 | 1.8 | 2.5 | 2.5 | 2.5 | 2.5 | 2.5 | 2.5 | 0.1 |
| AB310-1-2 | 2 | 0.15 | 2.7 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1 | |
| AB310-1-3 | 3 | 0.31 | 6.2 | 1.06 | 0.5 | 0.7 | 0.5 | 0.5 | 0.5 | 0.7 | |
| AB310-1-4 | 3.5 | 0.42 | 8.2 | 0.6 | 0.4 | 0.5 | 0.4 | 0.4 | 0.4 | 0.5 | |
| AB310-1-5 | 4 | 0.54 | 10.5 | 0.4 | 0.25 | 0.3 | 0.25 | 0.25 | 0.25 | 0.3 | |
| AB310-1-6 | 5 | 0.8 | 15.3 | 0.2 | 0.15 | 0.15 | 0.15 | 0.15 | 0.15 | 0.15 | |
| AB310-2-1 | ZG1/4 | 1.5 | 0.1 | 1.8 | 2.5 | 2.5 | 2.5 | 2.5 | 2.5 | 2.5 | 0.1 |
| AB310-2-2 | 2 | 0.15 | 2.7 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1 | |
| AB310-2-3 | 3 | 0.31 | 6.2 | 1.06 | 0.5 | 0.7 | 0.5 | 0.5 | 0.5 | 0.7 | |
| AB310-2-4 | 3.5 | 0.42 | 8.2 | 0.6 | 0.4 | 0.5 | 0.4 | 0.4 | 0.4 | 0.5 | |
| AB310-2-5 | 4 | 0.54 | 10.5 | 0.4 | 0.25 | 0.3 | 0.25 | 0.25 | 0.25 | 0.3 | |
| AB310-2-6 | 5 | 0.8 | 15.3 | 0.2 | 0.15 | 0.15 | 0.15 | 0.15 | 0.15 | 0.15 | |
| AB410-2-1 | ZG1/4 | 1.5 | 0.1 | 1.8 | 5 | 4 | 4.5 | 4 | 4 | 4 | 1 |
| AB410-2-2 | 2 | 0.15 | 2.7 | 3 | 2.5 | 2.7 | 2.5 | 2.5 | 2.5 | 1 | |
| AB410-2-3 | 3 | 0.31 | 6.2 | 1.5 | 0.9 | 1.3 | 0.9 | 0.9 | 0.9 | 1.3 | |
| AB410-2-4 | 3.5 | 0.42 | 8.2 | 1.2 | 0.6 | 0.9 | 0.6 | 0.6 | 0.6 | 0.9 | |
| AB410-2-5 | 4 | 0.54 | 10.5 | 1 | 0.5 | 0.7 | 0.5 | 0.5 | 0.5 | 0.7 | |
| AB410-2-6 | 5 | 0.8 | 15.3 | 0.6 | 0.25 | 0.4 | 0.25 | 0.25 | 0.25 | 0.4 | |
| AB410-2-7 | 7 | 1 | 26.4 | 0.25 | 0.1 | 0.2 | 0.1 | 0.1 | 0.1 | 0.2 | |
| AB410-3-1 | ZG3/8 | 1.5 | 0.1 | 1.8 | 5 | 4 | 4.5 | 4 | 4 | 4 | 1 |
| AAB410-3-2 | 2 | 0.15 | 2.7 | 3 | 2.5 | 2.7 | 2.5 | 2.5 | 2.5 | 1 | |
| AB410-3-3 | 3 | 0.31 | 6.2 | 1.5 | 0.9 | 1.3 | 0.9 | 0.9 | 0.9 | 1.3 | |
| AB410-3-4 | 3.5 | 0.42 | 8.2 | 1.2 | 0.6 | 0.9 | 0.6 | 0.6 | 0.6 | 0.9 | |
| AB410-3-5 | 4 | 0.54 | 10.5 | 1 | 0.5 | 0.7 | 0.5 | 0.5 | 0.5 | 0.7 | |
| AB410-3-6 | 5 | 0.8 | 15.3 | 0.6 | 0.25 | 0.4 | 0.25 | 0.25 | 0.25 | 0.4 | |
| AB410-3-7 | 7 | 1 | 26.4 | 0.25 | 0.1 | 0.2 | 0.1 | 0.1 | 0.1 | 0.2 | |
| AB410-3-8 | ZG3/8 | 10 | 1.88 | 40.6 | 0.1 | 0.05 | 0.1 | 0.05 | 0.05 | 0.05 | - |
| AB410-4-8 | ZG1/2 | 10 | 1.88 | 40.6 | 0.1 | 0.05 | 0.1 | 0.05 | 0.05 | 0.05 | - |
| 項目 | AB310 GAB310 | AB410 GAB410 | |||||||||
| 額定電壓(V) | AC:110,220,24, DC:12,24,48,100 | ||||||||||
| 頻率(Hz) | 50 | 60 | 50 | 60 | |||||||
| 視在功率(VA) | 起動時 | 20 | 16 | 35 | 27 | ||||||
| 保持 | 14 | 11 | 22 | 17 | |||||||
| 消耗功率(W) | AC | 6 | 4.2 | 8.3 | 6.2 | ||||||
| DC | 11 | 11 | 11 | 11 | |||||||
| 許可電壓范圍 | ±10% | ||||||||||
外形尺寸：
GAB410-2-5,GAB410-2-6,GAB410-2-7
