4B3.150-6/4V,4B3.135-7/4V,4B3.45-19/4.0B,4B3.40-13/4.0B,4B3.80-16/7.5B,變壓器油泵
變壓器油泵主要技術參數
|
型號Type |
功率kW |
電流A |
流量m3/h |
揚程m |
轉速r/min |
|
4B3.150-6/4V |
4 |
8.8 |
150 |
6 |
1450 |
|
4B3.135-7/4V |
4 |
8.8 |
135 |
7 |
|
|
4B3.45-19/4.0B |
4 |
8.8 |
45 |
19 |
|
|
4B3.40-13/4.0B |
4 |
8.8 |
40 |
13 |
|
|
4B3.100-9/5.5V |
5.5 |
11.6 |
100 |
9 |
|
|
4B3.80-16/7.5B |
7.5 |
16.6 |
80 |
16 |
4B3.150-6/4V,4B3.135-7/4V,4B3.45-19/4.0B,4B3.40-13/4.0B,4B3.100-9/5.5V,4B3.80-16/7.5B,
QB.25-16/1.7T,QB.25-16/1.7D,QB.41.5-11.5/2.2T,YB.40-16/3T,YB2.40-16/3T,YB.45-19/4D,YB2.45-19/4D,YB2.85-17/7.5T,B3.25-16/1.7V,B3.25-16/1.7B,B3.41.5-11.5/2.2V,B3.41.5-11.5/2.2B,B3.40-16/3V,B3.45-19/4.0B,B4.45-16/4B,B3.80-20/10B,B3.45-35/10B,4B3.45-4.5/1.1V,4B3.45-6/1.5V,4B3.20-19/2.2V,4B3.20-19/2.2B,4B3.80-4.5/2.2V,4B3.60-3.7/2.2V,4B3.40-16/3V,4B3.60-10/3V,4B3.63-10/3V,4B3.135-4.5/3V,4B3.120-5/3V,4B3.100-7/3V,4B3.100-8/3V,4B3.150-6/4V,4B3.135-7/4V,4B3.45-19/4B,4B3.40-13/4B,4B3.100-9/5.5V,4B3.80-16/7.5B,4B3.180-25/22.5B,
|
|
|
|
|
|
|
|
