How to order
|
PW-3000-02
|
PW-3000-03
|
|
Port size
|
G 1/4”
|
G 3/8”
|
|
Max. supply pressure
|
15 kgf/cm2
|
|
|
Max. operating pressure
|
9.9 kgf/cm2
|
|
|
Regulating range
|
0.5~8.5 kgf/cm2
|
|
|
Port size for pressure gauge
|
G 1/8”
|
|
|
Ambient and media temperature
|
5~60 ℃
|
|
|
Filter element
|
Standard：5μm Option：2,10μm
|
|
|
Bowl capacity
|
20 cm3
|
|
|
Bowl material
|
Polycarbonate
|
|
|
Weight
|
0.64 kgf
|
|
Accessories
|
How to order
|
Appellation
|
|
AD53
|
Float type auto drain (N.C)
|
|
W432
|
Bracket
|
|
K40110
|
1/8 PT Pressure gauge 0~10bar
|
