點擊圖片查看原圖
| 缸徑 | 32 | 40 | 50 | 63 | 80 | 100 |
| 工作介質 | 經過濾的壓縮空氣 | |||||
| 動作型式 | 雙動 | |||||
| 耐壓試驗壓力 | 1.5Mpa（15kgf/cm2) | |||||
| 最高使用壓力 | 1.0Mpa(10kgf/cm2) | |||||
| 最低工作壓力 | 0.1Mpa（1kgf/cm2) | |||||
| 緩沖 | 氣緩沖 | |||||
| 環境溫度 | (-10℃～60℃) | |||||
| 使用速度 | 50～500mm/s | |||||
| 行程誤差 | 0～250:0～+1.0,251～1000:0～+1.5 | |||||
| 1001～1500:0～2.0 | ||||||
| 使用壽命 | 不低于3000KM | |||||
| 潤滑 | 不需要 | |||||
| 接管口徑 | (1/8) | (1/4) | (3/8) | (1/2) | ||
| 缸徑 | 標準行程 | 緩沖行程 | 磁性開關 | 固定碼 |
| (mm) | （mm) | (mm) | ||
| 32 | 25，50，75 100,125,150,175 200,250,300,400,500 |
18.8 | D-A54 | DXT30 |
| 40 | 18.8 | 工作電壓 | ||
| 50 | 21.3 | DC24V | ||
| 63 | 21.3 | AC110V/220V | ||
| 80 | 30.3 | 工作電流 | DXT35 | |
| 100 | 29.3 | 5-50/25/12.5mA |
使用注意事項：
1、使用的電壓及電流避免超負荷。
2、嚴禁磁性開關直接與電源接通，必須同負載串聯使用。
3、嚴禁有其它強磁體靠近磁性開關，如有應屏蔽。SCGB32-25,SCGB32-50,SCGB32-75,SCGB32-100,SCGB32-125,SCGB32-150,SCGB32-175,SCGB32-200,
